WHEEL TURTLE™ is an innovative sensor module designed to mount in a wheel arch.  Each WHEEL TURTLE™ collects data on 8 Temperature points across the face of each tyre, plus distance to wheel for suspension movement and tyre colour RGB values.

WHEEL TURTLE™ can stream LIVE by Bluetooth to the Team Plus™ TELDASH™ smart phone app, RaceChrono smart phone app, OR to your CANbus race dash and data logger using Team Plus™ CANGATE for WHEEL TURTLE™.

The Wheel Turtle is all about giving you real time and logged data that can be used to really get the tyre settings and driver styles right.

So what are the top reasons to use the Wheel Turtle system?

For the driver at test days:
–  driver learn best techniques for warming tyres at test days
–  Understand your cornering and braking technique impact on tyre temps and therefore condition/longevity. Good for tyre management.

For car setup / engineering:
–  See the impact of camber adjustments visually and in the logged data to get that ideal setting.
–  Use the data from tyres and visualisations to see over or under inflation of the tyre by looking at edge heat vs centre heat on each.

For driver on race day:
–  One glance colour visualisation to know if the tyres are ready for that qualifying or sprint best lap.
–  On a safety car restart, monitor and know how warm the tyres are.
Get visual overheated tyre warning so you know when to back off to preserve the tyre.
–  Immediately visualise the level of hotspot/flat spot damage from a lockup.



From the Team Plus™ TELDASH™ smart phone app you can:
- Read temperatures in C or F on each tyre in graphical format
- View colour coded temperatures with configurable thresholds for Blue (cold), Green (ideal),  Orange (warning), and Red (over temp) Record peak(max) temperatures for each of the 32 temperatures, for easy review after drive.
- Watch live Thermal Image for any tyre
- View location and Motion Data
- Record your on track session data on the phone
- Live stream to friends or teammates
- Save and send recordings to another device
Integrate Wheel Turtles with your chosen CANbus capable loggers and dash.
- One Glance Tyre temp visualisations for driver using the 3.5” touch screen on CANGate as a secondary display.
- Display tyre temperature data on your existing race dash when integrated with CANbus
- Data Logging and analysis via your existing data logger when integrated with CANbus
- On-screen tick box options to set CANbus
speed, with more details settings available using the Teledash iPhone app.
- Publicly available CANbus protocol and dbc file for easy configuration into your dash or logger.
- Known configurations for:
- Motec Cxx
- ECU Master
- AiM Dash Loggers
- VBOX Video, Video VBOX, VBOX Touch
- LINK Display (using AiM product)
Combine Wheel Turtle with TELELOGGER to:
- Data sent to TELELOGGER™ live through bluetooth.
- Log data locally to TELELOGGER™ SD Card;   and/or
- Transmit data from TELELOGGER™ with 4G SIM Card
- TELEDASH™ phone app can view live or replay data from TELELOGGER™ over internet.
RaceChrono Pro plus Wheel Turtle is a strong solution for track day racers including:
- Lap Timing
- GPS and other device integration
- Tyre Temperature visualisation
- Tyre Temps added to analaysis data
- Video Overlay exports with Tyre Temps
- Racelogic format data export including the Wheel Turtle Data

Wheel Turtle Technology

Bluetooth Low Energy (BLE)

12 data points are transmitted between 8 and 10 times per second from each Wheel Turtle using efficient and easy to connect Bluetooth 4.x/5.x Technology.

Infra-Red Thermal Array

A 16x12 thermal array in each Wheel Turtle is used to provide 8 Temperatures across each tyre face and a thermal image

LIDAR distance sensor

Each Wheel Turtle contains a LIDAR distance sensor poroviding information on distance to the tyre. This can be used for Suspension Travel measurement.

RGB Colour Sensor

The Wheel Turtle constantly captures the colour of the tyre using an RGB colour sensor. This has potential to provide tyre aging information and instant debris alerts.

Client testimonials

The Team Plus TELELOGGER enabled me to consolidate important driver data from OBD and provide quality 10Hz GPS and accelerometer data into one device, replacing several others and even connected my external Boost Gauge data. Valuable tool for improving my Track Day Skills. I am keen to now try the TELEHUB and WHEEL TURTLE solutions

Track Day Success



For those who love to geek out at data I found this pretty amazing and cool. Team Plus Telemetry during WTAC installed their new Wheel Turtle IR data loggers/cameras onto my car and just happened to be on the session I did my PB. Unfortunately I didnt have the GoPro running that session and the GPS dropped out on the data loggers half way through the first lap. The loggers show the tyre surface temp across the entire tyre face. ....... The data clearly shows how the tyre pressures impact surfacce temps and also shows that at least 1-2 warm-up laps are needed for the first session. .... All in all I thought it was fantastic and for less than $1000 I think it is money very well spent. Unfortunately they only have Apple app for the time being but soon to get android out and ill be buying a set for myself. - World Time Attack Competitor

All in all I thought it was fantastic



Designed for all levels of motorsport, the TEAM PLUS WHEEL TURTLE® PRO tire temperature sensor has won the coveted BEST NEW PERFORMANCE RACING PRODUCT AWARD and a global media award at the SEMA SHOW 2023. Get your Tire Temps right.



Wheel Turtle WT1 Model Features:

  • Adjustable head moving around 80 degrees to allow extra mounting position options.
  • Internal battery for easy install and movement between vehicles
  • Micro USB port for charging and software updates.
  • Power Switch for battery management
  • 59 x 46 x 20mm (head flat) or 59 x 46 x 27mm (head raised) and only 35 grams including battery.
  • 110 degree field of vision
